SpiroCombi -Steel -Magnet -Weld
A steel (microbubble) deaerator and dirt separator with magnet for standard flow rate (1.5 m/s) with a DN50 - DN150 weld connection
The benefits of the BC-LM SpiroCombi deaerator and dirt separators with magnet
- Combined separation system - removes circulating air and microbubbles effectively
- Improve cost control and energy efficiency
- Applicable with 50/50 Ethylene Glycol / Water (Volume)
- Very small particles, from 5 μm (= 0.005 mm), are separated and removed
- Including a magnet for extra protection and high efficient removal of magnetite
- Dirt can be discharged while the system is in operation
- No shut-off valves or bypass required
- Constant low pressure drop
- Weld connections
- Connection diameters from DN50 - DN150, larger connection diameters on request
- Exceptional guarantee
Product variants
Select the desired connection below and get all (technical) productdata!
Article number
BC050LM
Product type
SpiroCombi -DN50 -Magnet -Weld
The best place for a SpiroCombi in your system
The position of the SpiroCombi is important for optimal operation:
- In heating systems: Placement in the supply line is preferred, as the water is warmest here, which allows air bubbles to escape more easily.
- Alternative in case of lack of space: If placement in the supply line is not possible, the SpiroCombi also works effectively in the return line.
- In cooling systems: Here, placement in the return line, just before the water enters the cooling unit, is preferred to efficiently capture dirt.
