SpiroExpand MultiControl Modular DUO

The MultiControl Modular DUO is an automatic expansion and pressure-maintaining device. The unit contains 2 pumps (2x 50%) and 1 overflow valve. A separate storage tank is required.

The properties of the MultiControl Modular DUO :

  • 2 pumps (2x 50%)
  • 1 overflow valve (1x 100%)
  • At least 1 unpressurized expansion vessel needs to be added
  • Operational pressure range up to 4.0 to 16.0 bar
  • The maximum temperature at the point of connection: 70°C (over 70°C possible with auxiliary tank)
  • Maximum safety temperature in the system: 110°C
  • Maximum operating pressure (PN) up to: 25 bar

Product variants

Choose the desired variant below for all (technical) product data!

Article number EMCM-D1-4.0
Product type EMCM Duo-1 max 4bar
